性能特點

減速機帶動軸的旋轉速度與槳葉的結構會使物料重力減弱，隨著重力的缺乏，各物料存在顆粒大小、比重懸殊的差異在混合過程中被忽略。激烈的攪拌運動縮短了一次混合的時間，更快速、更高效。

即使物料有比重、粒徑的差異，在交錯布置的攪拌葉片快速劇烈的翻騰拋灑下，也能達到很好的混合效果。

雙軸漿葉無重力混合機可實現17%以下的噴霧操作，加液后黏度太大的物料不適合。可進行固（粉）－固（粉）（粉體粒度300－2000um）混合。

根據用產要求，還可以加裝噴液及夾套裝置，使之成固（粉）－液（含液量<15%的混合及干燥設備使用。

對比重、粒度差異較大的物料混合不生產分層離析現象。固一固混合在1：1000配比時，標準偏差十萬分之三～八。

混合速度快，一般粉體混合只需2-3分鐘左右。

低能耗，是一般混合機的1/4～1/10。本機間歇操作，出料閥采用雙開門放料，設手動式、氣動式出料形式。材質有碳鋼、不銹鋼兩種。

Feature

The rotation speed of the reducer drive shaft and the structure of the blade will weaken the material gravity. With the lack of gravity, the difference of the particle size and the proportion of the material is neglected in the mixing process. The intense mixing movement shortens the time of mixing, faster and more efficient.

Even if the material has a specific gravity, the difference in particle size, in the staggered arrangement of the mixing blade fast and violent throwing thrown, but also to achieve a good mixing effect.

Two-axis pulp without gravity mixer can achieve less than 17% of the spray operation, the viscosity of the material is not suitable for too much. Can be solid (powder) - solid (powder) (powder particle size 300-2000um) mixed.

According to the production requirements, can also be installed spray and jacket device, so that solid (powder) - liquid (liquid content of <15% of the mixing and drying equipment.

For the proportion of large, different size of the material mixture does not produce layered segregation phenomenon. Solid-solid mixing in the 1: 1000 ratio, the standard deviation of three thousandths to eight.

Mixing speed, the general powder mix only 2-3 minutes.

Low energy consumption, is the general mixer 1/4 ~ 1/10. The machine intermittent operation, the discharge valve with double open the door discharge, set the manual, pneumatic discharge form. Material is carbon steel, stainless steel two.
